ProjectIn September 2020, CFX began design on the Lake/Orange Expressway. The project will be broken into three segments and is expected to improve traffic flow and operation in the area.
Click here for the State Road 516 (Lake/Orange Expressway) Corridor Wide Fact Sheet
Lake/Orange County Connector Preferred Alternative – select to expand
Click here to view the Virtual Tour
_______________________________________________________________________
Segment 1 – State Road 516 from US 27 to Cook Road
Project Type: Design
Design of the new 1.6-mile four-lane expressway segment will include an interchange with US 27 and realignment of US 27 to accommodate the interchange while avoiding impacts to Lake Louisa State Park.
Design start: September 2020.
Anticipated design completion: Late 2022.
_______________________________________________________________________
Segment 2 – State Road 516 from Cook Road to the Lake/Orange County Line
Project Type: Design
Design of the 1.9-mile segment includes an interchange with the future extension of County Road 455 being planned by Lake County.
Design start: January 2021.
Anticipated design completion: Early 2023.
______________________________________________________________________
Segment 3 – State Road 516 from the Lake/Orange County Line to SR 429
Project Type: Design
Design of the 0.9-mile segment includes interchange ramps with Valencia Parkway, a systems interchange with SR 429, toll gantries at interchange ramps, and a segment of Valencia Parkway between the interchange ramps and Schofield Road. The interchange at SR 429 and Schofield Road will remain.
Design start: October 2020.
Anticipated design completion: Late 2022.
_______________________________________________________________________
Study Documents
- SR 516 CR 455 Display Board
- SR 516 DRAFT Noise Study Report 1-3-23
- SR 516 Noise Wall Typical Section
- SR 516 Segment Typical Section Display Board
- SR 516 Project Display Board
- SR 516 Public Meeting Video
- SR 516 Segment 1 Display Board
- SR 516 Segment 1 ASPIRE Display Board
- SR 516 Segment 1 US 27 Display Board
- SR 516 Segment 1 US 27 & Ramp Typical Section
- SR 516 Segment 1 US 27 Typical Section
- SR 516 Segment 2 Display Board
- SR 516 Segment 2 Typical Section
- SR 516 Segment 3 Display Board
- SR 516 Segment 3 Valencia Pkwy Display Board
- SR 516 Segment 3 SR 429 North Display Board
- SR 516 Segment 3 SR 429 South Display Board
_______________________________________________________________________
About Public Involvement
Public involvement and interagency coordination will be an integral part of the design process, and opportunities for public participation will be provided. CFX anticipates holding a virtual public meeting as part of this project.
Additional Information
Property owners near a proposed transportation project often want to know an agency’s process for buying needed private property. Click here for the Central Florida Expressway Authority’s policy on right-of-way acquisition.
For information gathered prior to the Design phase, please visit the Lake/Orange Expressway (formerly known as the Lake/Orange County Connector) Project Development & Environment Study page.
